Supports stable 120A current, suitable for a variety of welding conditions.
The torch has a long extension length, which allows precise welding in narrow or deep holes.
Air-cooled or water-cooled system ensures long time stable operation and prolongs service life.
Nozzle, electrode and other components can be quickly replaced, easy maintenance.
Can be interfaced with a variety of automation equipment or robotic systems, supporting customized interfaces.
Adopting high grade insulating material, high temperature resistance, anti-electricity leakage, to protect the safety of welders.
| Parameter | Specification |
|---|---|
| Model Number | DSPT12020-HQ |
| Tungsten Pole | 3.2mm |
| Current Range | 10-100A |
| Copper Nozzle Cooling Method | Direct water cooling |
| Ionized Gas | 1.0-3.0L/min |
| Protective Gas | 5-10L/min |
| Powder Feed Gas | 1.0-3.0L/min |
| Copper Nozzle Powder Runner | Two Way |
| Powder Feeding Capacity | 0-1.5KG/h |
| Welding Torch Return Water Flow | 3.6L/Min |
| Granularity | 100-270 mesh |
| Serial No. | Product Name | Material Code | Product Dimension (mm) |
|---|---|---|---|
| A | 120A deep hole welding torch (20 models) | D2120000 | / |
| 1 | 120A Deep Hole Rear Cap | D2020500 | 116*20 |
| 2 | 120A Deep Hole Rear Cap Rubber Ring | D2020510 | 13*2.4 |
| 3 | 120A Deep Hole Tungsten Pole Clamp | D2020400 | 12*10.5 |
| 4 | 120A Deep Hole Protection Air Ring | D2120800 | 22*205 |
| 5 | 120A deep hole copper nozzle small rubber ring | D2120600 | 10*1 |
| 6 | 120A Deep Hole Copper Nozzle Large Rubber Ring | D2120700 | 11*1.9 |
| 7 | 120A deep hole copper nozzle | D2120100 | 25*17 |
| 8 | 120A Deep Hole Locking Ring | D2120200 | 10*8 |
| 9 | 120A Deep Hole Protection Cover | D2120300 | 26*22 |
| 10 | 120A deep hole copper spout key | D2120400 | 110*30 |
| 11 | 120A deep hole centering ring | D2040201 | 31*8 |
| 12 | 120A deep hole tungsten needle | D2120500 | 3.2*350 |
| 13 | Tungsten pole calibrator (universal) | D2000100 | 10*32 |
The torch features a specialized long extension structure design, which allows it to reach and perform precise welding operations in narrow spaces and deep holes.
It supports a stable output current of 120A, operating efficiently within a standard welding current range of 10-100A depending on the application requirements.
It employs a direct water cooling system for the copper nozzle, with a return water flow rate of 3.6L/Min, ensuring optimal temperature control and long-term stable operation.
Yes. The torch is designed with a modular structure, allowing quick replacement of components like the nozzle, electrode, and rubber rings for easy maintenance.
The required gas flow rates are: Ionized Gas at 1.0-3.0L/min, Protective Gas at 5-10L/min, and Powder Feed Gas at 1.0-3.0L/min.
Yes, it features high compatibility that allows it to interface with a wide range of automation equipment and robotic systems, supporting customized interface setups.
